Settng the Tme Axs
Selecting absolute or relative time display and zooming in or zooming out on the time
axis
See section 4.2, “Displaying the Waveform.”
Selectng the dsplayed tme
Select the displayed time per cycle
Select the [Zoom In] or [Zoom Out]
Settng the Y-axs
Waveform display limit
See section 3.7, “Circular Display.”
Turnng ON/OFF the Alarm Dsplay
For details on the alarm display, see Alarm Display in section 3.7, “Circular Display.”
