6-6
IM WX104-01E
Ref. CH
The reference channel for difference computation.
Square Root
Computes and displays the square root of the input. This setting can be used only when
the input mode is set to VOLT (voltage). As necessary, set the span, scale, and unit.
Unt
Enter the unit using up to six characters.
Low-cut (Can be set when the mode s 1-5V, and when the mode s VOLT wth
square root (SQRT) selected. )
Select [ON] to use the low-cut function.
Low-cut value (Can be set when the mode s VOLT wth square root (SQRT)
selected.)
Set the low-cut value in the range of 0.0% to 5.0% of the input span.
Input value
Low-cut value
Result of square root computation
Measured value
Calbraton Correcton
Set the input and output values for the calibration correction. The number of set points
(including the start and end points) can be specified in the range 2 to 16.
Click to delete the selected row.
Click to add set points (rows) to the number of calibration set points.
Input
Number of set points
Calibration set points
Y5
Y4
Y3
Y2
Y1
Output
X1 X2 X3 X4
X5
Condition
X1 < X2 < X3 < X4 < X5
6.2 Settng the Measurement Channels, Ext. Channels
