ng the CX1000/CX2000
8.1 Startng the Hardware Confgurator (Openng
the Hardware Confgurator Wndow)
Startng the Hardware Confgurator
To open the Hardware Configurator of the connected CX, double-click the [CONFIG] icon
in the CX folder.
If you double-click a setup data file on the DAQ desktop and open the CX Configurator,
the CX Configurator of the data saved on the PC opens.
CX folder
1. Double-click here.
2. The CX Configurator opens.
Print (section 8.15)
Data check (section 8.12)
Display the version information of Hardware Configurator
Scroll through the screen (left and right)
Menu bar
Toolbar
Scroll through
the screen
(up and down)
Chapter 8 Confgurng the CX1000/CX2000
