ng the MV1000/MV2000
Settng One Channel at a Tme
2. The channel setting dialog box opens.
1. Double-click the
channel you wish to set.
Set the maximum possible value
Set the minimum possible value
For Ext channels
The items in the measurement channel tab can be configured for each channel. The
items that are configured are the same as those configured on the spreadsheet. For
details, see the page corresponding to the item.
7.2 Settng the Measurement Channels, Ext. Channels
