4-18 IM WX104-01E
4.6 Lstng Alarms and Marks and Convertng the
Lst
A list of alarms and marks is displayed with the display file or event file opened.
1. Click here([Window]-[Alarm/Mark]).
3. Click here([Alarm List]).
Pointer
2. The [Display File List]
dialog box opens.
Label
3. Click here([Mark List])
3. Click here([Event List])
Cursor
Mark created on
the viewer
Mark created on the DX/MV/CX
Trigger mark
DX/MV/CX display
DX1000/DX2000 display
