ng the DX1000/DX2000
Acton
The action to be executed when an event occurs.
Settngs Descrpton
Memory Start/Stop -
Memory Start -
Memory Stop -
Trigger Can be specified when the DX is configured to record event data.
AlarmACK Cannot be specified when the event is set to Relay, Switch, or Alarm.
Math Start/Stop Can be specified on /M1 and /PM1 options.
MathStart Can be specified on /M1 and /PM1 options.
MathStop Can be specified on /M1 and /PM1 options.
Math Reset Can be specified on /M1 and /PM1 options.
Save Display Data Can be specified when the DX is configured to record display data.
Save Event Data Can be specified when the DX is configured to record event data.
Message Set the message number to write the message and the destination. Set
the message destination to all groups (All) or a group number.
Snapshot -
Display Update Internal
change Can be specified when the function for switching between the trend
update interval and the secondary update interval is enabled.
Manual Sample -
Timer Reset Cannot be specified when the event is set to Timer.
Display Group Change Specify the number of the group to be displayed.
Flag Can be specified on /M1 and /PM1 options.
Time ADJUST Can be specified only when the event is set to Remote.
Panel Load Can be specified only when the event is set to Remote.
Alarm Display Reset
*
You can specify this when the annunciator sequence is set to use the
"ISA-M" annunciator and the event is set to [Remote], [User Key], or
[Edge].
Comment Display * Specify the comment text block number to display.
Favorite Display
*
Choose which registered display to switch to.
Set [Action] to [Key] or [Select].
Settngs Descrpton
Key Performs the same operation as pressing the favorite
key.
Select Displays the specified favorite screen. Set the registration
numbers of the screens you want to specify in the [No.]
boxes.
* Available in release numbers 3 and later.
When the multi batch function (/BT2 option; release number 3 or later) is enabled, specify
the target batch group when you set the action to any of the settings below.
Settngs that requre the
desgnaton of a specfc batch
group Memory Start/Stop
Memory Start
Memory Stop
Math Reset
Save Display Data
Save Event Data
Message
Display Group Change
