Page 211

7-15
IM WX104-01E
1
2
3
4
5
6
7
8
9
Index
Conf
gur
ng the MV1000/MV2000
Settng One Computaton Channel at a Tme
2. The channel setting dialog box opens.
1. Double-click the channel you wish to set.
Clicking here and selecting the list of operators switches the display
Select channels on the Measure channel, Math channel, and Ext channel
tabbed pages and select desired operators to create an expression.
The items in the math channel tab can be configured for each channel. The items that
are configured are the same as those configured on the spreadsheet. For details, see
the page corresponding to the item.
7.2 Settng the Measurement Channels, Ext. Channels
