Page 119

5-23
IM WX104-01E
Conf
gur
ng the DX100/DX200/MV100/MV200
1
2
3
4
5
6
7
8
9
Index
Network
TCP/IP Settngs
Connect the CX to the Ethernet and, in the dialog box below, enter TCP/IP settings.
Type the same address for [IP Address] as the one of the [Address] box of the [Network
Settings] dialog box.
1. Click here. (Or choose the [Setting] menu - [SETUP [Basic] Setting] - [Comm].)
2. Click this tab
Specify the
IP address
Enter the timeout value when
turned ON
Specify these
addresses when
using the DNS
Serial Communication Settings
When using serial communications between the CX and other devices, set the
parameters required for serial communications. In the [Protocol] settings, if [MODBUS
MASTER] is selected, you must to click the [Modbus master] tab and make Modbus
master settings.
Click this tab
5.5 Confgurng the Setup Mode
