4-11

IM WX104-01E

splay

ng Data w

th the Data V

ewer

Index

Deletng Marks

1. Place Cursor A and Cursor B so that

the mark is between the two.

2. Select [Edit] - [Delete Mark].

The arbitrary marks (green/yellow) and trigger marks (yellow) between Cursor A and

Cursor B are deleted.

Note

• The arbitrary marks placed on the Data Viewer are green. The arbitrary marks (messages)

and trigger points placed on the RECORDER are yellow.

• With Data Viewer, the maximum number of characters that can be entered for the name of a

mark is thirty-two (from revision R4.07).

Resettng Marks

All arbitrary marks created on the Data Viewer are erased by selecting [Edit] -
[Reset Mark]. The marks (messages) and the trigger point that were created on the
RECORDER but deleted on the Data Viewer are displayed again.

Settng the Wndow

Select how to sort the windows

Select the windows to be displayed

Changng the Grd Dsplay

Specify a grid type by clicking the grid density button on the toolbar, or by choosing
Y-axis on the menu bar. The grid display switches.

Switch the grid density

4.2 Dsplayng the Waveform
