5-28
IM WX104-01E
5.8
Checkng the System Confguraton and
Intalzng Setup Data
Checkng the System Confguraton
On the DX/MV Configurator of the connected DX100, DX200, MV100, or MV200,
selecting [System Configuration] from the [System] menu opens the [System
Configuration] dialog box. You can only view the system configuration on this [System
Configuration] dialog box.
2. The [System Configuration]
dialog box opens.
1. Select [System] -
[System Configuration].
Note
If you select [System Configuration] from the [System] menu on the DX/MV Configurator that
was opened by double-clicking the setup data file on the DAQ desktop or loading the setup
data, a [System Configuration] dialog box in which you can change the system configuration
opens. If the system configuration is changed in this dialog box and the [OK] button is clicked,
a message “System Configuration is changed Input&Data are Initialized” appears. Click the [OK]
button to initialize the data.
Intalzng the Setup Data
To initialize the settings, select [Initialize] from the [Setting] menu on the DX/MV
Configurator.
2. The [initialize confirmation]
dialog box opens.
1. Select [Setting] - [Initialize].
3. Execute the initialization.
