Graph
Dvsons
Select the number of bar graph divisions.
Bar graph
Select the reference position of the bar graph. Selecting [Center] when the bar graph is
vertical produces no effect.
It is set back to [Normal] when the data are checked.
Scale
When using scale display on the trend screen, select the position to display the scale.
For details related to divisions, bar graph, and scale, see section 7.10 in the DX100/
DX200/MV100/MV200 User’s Manual.
Partal Expanded Dsplay
Poston (%)
Set the boundary for the partial expanded display. The range is from 1 to 99%.
Boundary
The conditions used to set the boundary vary depending on the measurement and
computation channels as follows:
• Measurement channel
When SCALE and SQRT are not used: Span L < boundary < span U
When SCALE and SQRT are used:
Scale L < boundary < scale U
• Computation channel
Span L < boundary < span U
Note
The partial expansion settings take effect when the partial expansion function is set to [Use] in
the [Aux] section of the [Setup] tab.
Dsplay Color
You can select the display color of each channel from 16 colors.
Copyng and Pastng Setup Data
The items checked in [Copy Details] can be copied and pasted. Click the channel
number to select the copy source or paste destination.
To select multiple channels to be copied, drag the channel number to specify the range
to be copied. To select multiple copy destinations, select the range in a similar fashion.
Copyng and Pastng Setup Data
You can copy and paste settings by using the Copy, Paste, and Details buttons.
Selecting the Items to Copy and Paste
1. Click the Details button. A setting item selection screen is displayed.
2. Select the items to copy and paste. Choose items to copy and paste by selecting
the corresponding check boxes. Click the × button to close the setting item selection
screen.
