4 In the LACP row (the first row), toggle the button under the port number

to assign either the LACP or the static LAG.

5 In the LAG row (the second row), toggle the button to a specific number

to aggregate or remove the port to that LAG number.

Adding Ports to LAGs Using CLI Commands

The following table summarizes the CLI commands for assigning ports to

LAGs as displayed in the LAG Membership pages.

The following is an example of the CLI commands:

Table 13-2. LAG Membership CLI Commands

CLI Command

Description

channel-group

port-channel

mode

{

on

|

auto

}

no channel-group

Associates a port with a port-channel with or

without a LACP operation.
Use the no form of this command to remove

the channel-group configuration from the

interface.

show interfaces port-

channel

[

interface-id

]

Displays port-channel information for all port

channels or for a specific port channel.

console(config)# interface gi0/8

console(config-if)# channel-group 1 mode on
