The following is an example of the CLI commands:
LAG Settings
VLANs can either be composed of individual ports or of LAGs. Untagged
packets entering the device are tagged with the LAGs ID specified by the
PVID.
To configure LAGs on a VLAN:
1 Click Switching > VLAN > LAG Settings in the tree view to display the
VLAN LAG Settings page.
All LAGs and their settings are displayed.
console(config)# vlan database
console(config-vlan)# vlan 23-25
console(config-vlan)# end
console(config)# interface vlan 23
console(config-if)# name Marketing
console(config-if)# end
console(config)# interface gi0/5
console(config-if)# switchport mode access
console(config-if)# switchport access vlan 23
console(config-if)# end
console(config)# interface gi0/6
console(config-if)# switchport mode trunk
console(config-if)# switchport mode trunk allowed vlan add
23-25
console(config-if)# end
console(config)# interface gi0/8
console(config-if)# switchport mode general
console(config-if)# switchport general allowed vlan add
23,25 tagged
console(config-if)# switchport general pvid 25
