Defining Protocol Groups
Define protocol groups in two steps:
1 Define a protocol group by assigning one or more protocols to the group
and giving it a protocol-group ID (any integer), using the Protocol Group
pages.
2 Associate the group with a desired VLAN classification, per port, using the
Protocol Port pages.
To define a protocol group:
1 Click Switching > VLAN > Protocol Group in the tree view to display
the Protocol Group: Summary page.
The currently-defined protocol groups are displayed.
2 To add a new protocol group, click Add, and enter the fields:
–
Frame Type — Select a frame type to be accepted in the protocol
group.
–
Protocol Value — Select a protocol name.
or
–
Ethernet-Based Protocol Value (0600 - FFFF) — Enter the Ethernet
protocol group type.
–
Protocol Group ID — Assign a protocol group ID number.
Defining VLAN Protocol Groups Using CLI Commands
The following table summarizes the CLI commands for defining VLAN
Protocol groups.
Table 12-3. VLAN Protocol Groups CLI Commands
CLI Command
Description
map protocol protocol
[encapsulation-value]
protocols-group group
no map protocol protocol
[encapsulation]
Maps a protocol to a protocol group.
Protocol groups are used for protocol-
based VLAN assignment.
Use the no form of this command to
delete a protocol from a group.
