The following is an example of some of the CLI commands:
ACL Binding
When an ACL is bound to an interface, all the rules that have been defined
for the ACL are applied to that interface. Whenever an ACL is assigned on a
port or LAG, flows from that ingress or egress interface that do not match the
ACL, are matched to the default rule, which is to Drop unmatched packets.
deny protocol {any |{source-prefix/length}
{any | destination-prefix/length} [dscp
number | precedence number] [time-range
time-range-name] [disable-port | log-
input]
deny icmp {any {source-prefix/length} {any
| destination-prefix/length} {any | icmp-
type} {any | icmp-code} [dscp number |
precedence number] [time-range time-range-
name] [disable-port | log-input]
deny tcp {any | {source-prefix/length} {any
| source-port/port-range}} {any |
destination-prefix/length} {any |
destination-port/port-range} [dscp number
| precedence number] [match-all list-of-
flags] [time-range time-range-name]
[disable-port | log-input]
deny udp {any | {source-prefix/length}}
{any | source-port/port-range}} {any |
destination-prefix/length} {any |
destination-port/port-range} [dscp number
| precedence number] [time-range time-
range-name] [disable-port | log-input]
Sets deny conditions
for IPv6 access list (in
Access List
Configuration mode).
console(config)# ipv6 access-list server
console(config-ipv6-al)# permit tcp 3001::2/64 any any 80
Table 7-7. IP-Based ACE CLI Commands (Continued)
CLI Command Description
