208

FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Plasma\User

Guide\Plasma_UGSwitching_NetworkSecurity.fm

D E L L C O N F ID E N T IA L – P R E L IM I N A RY 4 / 1 8 /1 3 - F O R P R O O F O N LY

Configuring MAC-Based ACLs Using CLI Commands

The following table summarizes the CLI commands for configuring

MAC-based ACLs

.

The following is an example of some of the CLI commands:

MAC-Based ACEs

To add rules to an ACL:

1 Click Switching > Network Security > MAC Based ACE to display the

MAC Based ACE: Summary page.
The currently-defined rules for the selected ACL are displayed.

2 To add a rule click Add ACE.
3 Select the ACL for which a rule is being created.
4 Enter the fields:

New Rule Priority — Enter the priority of the ACE. ACEs with higher

priority are processed first. One is the highest priority

Source MAC Address — Match the source MAC address from which

packets have arrived to this source address. In addition to the Source

MAC address, you can enter a Wildcard Mask that specifies which

bits in the source address are used for matching and which bits are

Table 7-2. MAC Based ACL CLI Commands

CLI Command

Description

mac access-list extended acl-

name

no mac access-list extended acl-

name

Defines an ACL and places the device

in MAC-extended ACL configuration

mode.
Use the no form of this command to

remove the ACL.

show interfaces access-lists

[interface-id]

Displays access lists applied on

interfaces.

console# show access-lists

Extended IP access list ACL1

permit 234 172.30.40.1 0.0.0.0 any

permit 234 172.30.8.8 0.0.0.0 any
