Protected Port Restrictions
The following restrictions apply to protected ports:
• When a protected port is placed in a LAG, it loses its protected port
attribute and takes upon itself the LAG's protection attributes. When the
port is removed from the LAG, its attributes are re-applied.
• Mirrored traffic is not subject to protected ports rules.
• Routing is not affected by the protected port forwarding rule, so that if a
packet enters a protected port, it can be routed by the device to another
protected port.
Protected Port Configuration
To configure protected ports and establish their communities:
1 Click Switching > Ports > Protected Ports in the tree view to display the
Protected Ports: Summary page.
A summary of all the ports and their statuses is displayed.
2 Click Edit.
3 Select the unit and interface.
4 Enter values for the following fields:
• State — Select Protected/Unprotected to enable/disable port
protection.
• Community — Select the community to which to add the port, or
define the port as Isolated.
Configuring Protected Ports Using CLI Commands
The following table summarizes the CLI commands for configuring
protected ports.
Table 8-4. Protected Ports CLI Commands
CLI Command Description
switchport protected-port
no switchport protected-port
Isolates Unicast, Multicast, and Broadcast
traffic on a port at Layer 2 from other
protected ports on the same switch.
Use the no form of this command to
disable protection on the port.
