The following is an example of the CLI commands:
Voice VLAN
The Voice VLAN feature enables you to enhance VoIP service by configuring
ports to carry IP-voice traffic from IP phones on a specific VLAN. This VLAN
is configured with a QoS profile that ensures high voice quality.
Equipment, such as VOIP phones, transmits IP traffic with a pre-configured
Organizational Unique Identifier (OUI) prefix in the source MAC address.
This enables the switch to dynamically identify ports connected to the VoIP
equipment and automatically add these ports to the Voice VLAN.
IP phones use one of the following modes, both of which are supported by the
device:
• Use only tagged packets for all communications.
• Initially use untagged packets while retrieving the initial IP address
through DHCP. Then the phone uses the Voice VLAN and starts sending
tagged VoIP packets.
Non-VoIP traffic is dropped from the Voice VLAN when the device is in Auto
Voice VLAN secured mode.
The Voice VLAN feature also provides QoS actions to VoIP, ensuring that the
quality of voice does not deteriorate if the IP traffic is received unevenly.
To summarize, when Voice VLAN is enabled and configured, and VoIP
equipment is connected to one of the switch ports, the VoIP traffic triggers
the switch’s Voice VLAN feature to add this port to the Voice VLAN (a VLAN
that usually carries only voice traffic), and to assign traffic from this port a
specific QoS profile, ensuring high voice quality.
The device supports a single voice VLAN.
console# show vlan private-vlan
Primary Secondary Type Ports
-------- --------- ---------- ---------------------
20 Primary gi0/1-2
20 201 Isolated gi0/1-8
20 202 Isolated gi0/1-2 gi0/5-7
20 203 Isolated gi0/1-2 gi0/2-3
