G-code Tables
Appendix C
C-4
A Type Function Modal C B
G75 G75 G77 O.D. and I.D. Grooving Cycle
G76 G76 G78 O.D. and I.D. Multi-Pass Threading Routine
G80 09 Cancel or end fixed cycle Modal
G81 Drilling cycle (no dwell, rapid out)
G82 Drilling cycle (dwell, rapid out)
G83 Deep hole peck drilling cycle
G83.1 Deep hole peck drilling cycle (dwell)
G84 Right hand tapping cycle
G84.1 Left hand tapping cycle
G84.2 Right hand solid tapping cycle
G84.3 Left hand solid tapping cycle
G85 Boring cycle (no dwell, feed out)
G86 Boring cycle (spindle stop, rapid out)
G86.1 Boring cycle (spindle shift)
G87 Back boring cycle
G88 Boring cycle (spindle stop, manual out)
G89 Boring cycle (dwell, feed out)
---- G90 G90 03 Absolute mode
---- G91 G91 Incremental mode
G50 G92 G92 00 Coordinate offset using tool positions Nonmodal
G50 G92 G92 Maximum CSS Spindle RPM
G92.1 Coordinate system offset cancel
G92.2 Cancel select offsets
G98 G94 G94 05 Feed per minute mode Modal
G99 G95 G95 Feed per revolution mode
G96 17 CSS ON Modal
G97 RPM Spindle Speed Mode
---- G98 G98 10 Initial level return drilling cycles Modal
---- G99 G99 R-point level return drilling cycles
END OF APPENDIX
