Introduction to Programming
Chapter 10
10-26
Table 10.E (continued)
G-code Table
A B C Modal Function Type
G59.2 Preset Work Coordinate System 8
G59.3 Preset Work Coordinate System 9
G61 13 Exact Stop Mode Modal
G62 Automatic Corner Override
G63 Tapping Mode
G64 Cutting Mode
G65 00 Paramacro Call Non-Modal
G66 14 Paramacro call Modal
G66.1 Paramacro call
G67 Paramacro call cancel
G20 G20 G70 06 Inch system selection Modal
G21 G21 G71 Metric system selection
G70 G70 G72 00 O.D. and I.D. Finishing Cycle Non-modal
G71 G71 G73 O.D. and I.D. Roughing Cycle
G72 G72 G74 Rough facing cycle
G73 G73 G75 Casting/forging roughing cycle
G74 G74 G76 Face Grooving Cycle
G75 G75 G77 O.D. and I.D. Grooving Cycle
G76 G76 G78 O.D. and I.D. Multi-Pass Threading Routine
G80 09 Cancel or end fixed cycle Modal
G81 Drilling cycle (no dwell, rapid out)
G82 Drilling cycle (dwell, rapid out)
G83 Deep hole peck drilling cycle
G83.1 Deep hole peck drilling cycle (dwell)
G84 Right hand tapping cycle
G84.1 Left hand tapping cycle
G84.2 Right hand solid tapping cycle
G84.3 Left hand solid tapping cycle
G85 Boring cycle (no dwell, feed out)
G86 Boring cycle (spindle stop, rapid out)
G86.1 Boring cycle (spindle shift)
G87 Back boring cycle
G88 Boring cycle (spindle stop, manual out)
G89 Boring cycle (dwell, feed out)
---- G90 G90 03 Absolute mode Modal
---- G91 G91 Incremental mode
G50 G92 G92 00 Coordinate offset using tool positions Non-modal
G50 G92 G92 Maximum CSS Spindle RPM
G92.1 Coordinate system offset cancel
G92.2 Cancel select offsets
G98 G94 G94 05 Feed per minute mode Modal
