Paramacros
Chapter 28
28-22
#5001 to 5012
Coordinates of End Point
These parameters are read-only. They correspond to the coordinates of the
end point (destination) of a programmed move. These are the coordinates
in the work coordinate system.
5001 Axis 1 coordinate position 5007 Axis 7 coordinate position
5002 Axis 2 coordinate position 5008 Axis 8 coordinate position
5003 Axis 3 coordinate position 5009 Axis 9 coordinate position
5004 Axis 4 coordinate position 5010 Axis 10 coordinate position
5005 Axis 5 coordinate position 5011 Axis 11 coordinate position
5006 Axis 6 coordinate position 5012 Axis 12 coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
#5021 to 5032
Coordinates of Commanded Position
These parameters are read-only. They correspond to the current
coordinates of the cutting tool. These are the coordinates in the work
coordinate system.
5021 Axis 1 coordinate position 5027 Axis 7 coordinate position
5022 Axis 2 coordinate position 5028 Axis 8 coordinate position
5023 Axis 3 coordinate position 5029 Axis 9 coordinate position
5024 Axis 4 coordinate position 5030 Axis 10 coordinate position
5025 Axis 5 coordinate position 5031 Axis 11 coordinate position
5026 Axis 6 coordinate position 5032 Axis 12 coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
