Running a Program
Chapter 7
7-7
This screen appears:
ACTIVE
PRGRAM
EDIT
PRGRAM
RESTRT
PRGRAM
DISPLY
PRGRAM
COPY
PRGRAM
SELECTED PROGRAM:
DIRECTORY PAGE 1 OF 1
NAME SIZE COMMENT
TEST AE 3.9
O12345 1.3 SUB TEST 1
MAIN 1.3
SHAFT2 1.3 THIS IS A TEST PROGRAM
XXX 1.3
5 FILES 137.8 METERS FREE
Important: This screen shows program TEST as active and being edited.
Make sure no part program is currently already active. If a part program
is currently active, the control cannot select a different part program until
the currently active one is deactivated. See page 7-8 to learn how to
deactivate a part program.
If a program is: This appears to the right
of a program name:
active A
being edited E
2. Key in the name of the part program to activate. If the program is
being selected from control memory, the
Ý or ß cursor keys may be
used to select the program to activate from the directory screen.
If the part program is being selected from a peripheral device
(attached to port A or port B), you must manually key in the part
program name. Make sure the peripheral device is on and ready to
output the part program. You might need to perform a search
operation when selecting a program from a peripheral device to find
the tape location containing the desired part program.
