Editing Programs On Line

Chapter 5

5-26

SELECT

DRILL

PROMPT

MENU DISPLAY

G80: CANCEL OR END FIXED CYCLE

G81: DRILLING CYCLE, NO DWELL/RAPID OUT

G82: DRILLING CYCLE DWELL/RAPID OUT

G83: DEEP HOLE DRILLING CYCLE

G83.1: DEEP HOLE PECK DRILLING CYCLE, DWELL

G84: RIGHT HAND TAPPING CYCLE

G84.1: LEFT HAND TAPPING CYCLE

G85: BORING CYCLE, NO DWELL/FEED OUT

G86: BORING CYCLE SPINDLE STOP, RAPID OUT

G86.1: BORING CYCLE, SPINDLE SHIFT

G87: BACK BORING CYCLE

G88: BORING CYCLE, SPINDLE STOP/MANUAL OUT

G89: BORING CYCLE, DWELL/FEED OUT

Position the cursor at the desired cycle to prompt by using the up and

down cursor keys. The selected cycle appears in reverse video.

Once you select the correct cycle code, press the

{SELECT}

softkey.

A screen with prompts for that cycle appears along with a graphical

representation of the cycle.

Use the up and down cursor keys to select the parameters to be

changed or entered. The selected parameter appears in reverse video.

Axis words followed by a (1), (2), or (3) are prompting for the first,

second, or third coordinate position respectively. The location of the

first, second, or third axis word appears on the drawing

accompanying the prompt screen.

Prompts that are shown: Indicate that:

in reverse video

this parameter is optional and does not need to be

entered in this block,

with an OR to the left of

the prompt

there are two more optional parameters for this

prompt, only one of which needs a value assigned.

Type in the desired data for that parameter on the input line of the

CRT, and press the

[TRANSMIT]

key.

After you enter all data for the G-code, store the data by pressing the

{STORE}

softkey.
