Paramacros
Chapter 28
28-28
5301 G58 Axis 1 Coordinate
5302 G58 Axis 2 Coordinate
5303 G58 Axis 3 Coordinate
5304 G58 Axis 4 Coordinate
5305 G58 Axis 5 Coordinate
5306 G58 Axis 6 Coordinate
5307 G58 Axis 7 Coordinate
5308 G58 Axis 8 Coordinate
5309 G58 Axis 9 Coordinate
5310 G58 Axis 10 Coordinate
5311 G58 Axis 11 Coordinate
5312 G58 Axis 12 Coordinate
The system installer determines in AMP the name (or word) that is used to
define the axis.
#5630
S- Curve Time per Block
This parameter is read only. The value represents the amount of time
(seconds converted to system scans) for a part program block’s S--Curve filter
where S--Curve Acc/Dec is applied during G47.1 mode. When it is
multiplied by the scan time, the product equals the amount of time required
by the acceleration.
This parameter is only calculated for blocks that have programmed motion
with S--Curve Acc/Dec.
#5631 to 5642
Acceleration Ramps for Linear Acc/Dec Mode
These parameters are read only. They correspond to the active acceleration
ramps in Linear Acc/Dec mode. You can set these parameters by
programming a G48.1 in your part program block. Control Reset, Program
End (M02/M03), or G48 will reset these values to their default AMP values.
For more information about programming G48.x codes, refer to chapter 18 in
your 9/Series CNC Operation and Programming Manual.
5631 Axis 1 acceleration ramp 5637 Axis 7 acceleration ramp
5632 Axis 2 acceleration ramp 5638 Axis 8 acceleration ramp
5633 Axis 3 acceleration ramp 5639 Axis 9 acceleration ramp
5634 Axis 4 acceleration ramp 5640 Axis 10 acceleration ramp
5635 Axis 5 acceleration ramp 5641 Axis 11 acceleration ramp
5636 Axis 6 acceleration ramp 5642 Axis 12 acceleration ramp
