Dual Axis Operation
Chapter 19
19-3
Figure 19.2 shows the position display for a system that contains a dual
axis group containing two axes with a master axis name of X. Whether or
not all axes of a dual group show up on the position display is determined
in PAL by your system installer.
Figure 19.2
Axis Position Display for Dual X Axis
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
E-STOP
PROGRAM[ MM ] F 0.000 MMPM
X1 -7483.647 S 00
Z -0219.550 T 0
U -2345.673 (ACTIVE PROGRAM NAME)
X2 -7483.647
MEMORY MAN STOP
This feature allows you or the programmer to disable selected axes of the
dual group. Any axis that is a member of a dual axis group can be parked.
Axes in the dual group may be parked simultaneously. If all axes in the
group are parked, no motion can take place in the dual axis group.
Once parked, no motion is allowed on the parked axis. Programmed and
jog commands (including any homing requests) made to the dual axis
group are ignored by the parked axes.
Axes in the dual group may only be parked or unparked when the control
is in cycle stop and end-of-block state. The control cannot be in the
process of completing any jog request or PAL axis mover request. If an
attempt is made to park/unpark an axis, and if any one of the above
requirements is not true, the control ignores the request to park/unpark the
axis.
19.1
Parking a Dual Axis
