G-code Tables
Appendix C
C-2
A Type Function Modal C B
G12.1 21 Spindle 1 Controlling Modal
G12.2 Spindle 2 Controlling
G12.3 Spindle 3 Controlling
G13 00 QuickPath Plus (Use First Intersect.) Nonmodal
G13
00
QuickPath Plus (Use Second Intersect.)
Nonmodal
G14 19 Scaling (Disable) Modal
G14.1 Scaling (Enable)
Modal
G15 15 Virtual C (Cancel)
G16.1 Virtual C Cylindrical Interpolation
G16.2 Virtual C End Face Milling
G17 02 Plane Selection
G18 Plane Selection
G19 Plane Selection
G90 G77 G20 01 Single Pass O.D. and I.D. Roughing
G92 G78 G21 Single Pass Thread Cycle
G94 G79 G24 Single Pass Rough Facing Cycle
G22 04 Programmable Zone 2 and 3 (On)
G22.1 Programmable Zone 3 (On)
G23 Programmable Zone 2 and 3 (Off)
G23.1 Programmable Zone (Off)
G27 00 Machine Home Return Check Nonmodal
G28 Automatic Return to Machine Home
G29 Automatic Return from Machine Home
G30 Return to Secondary home
G31 External Skip Function 1
G31.1 External Skip Function 1
G31.2 External Skip Function 2
G31.3 External Skip Function 3
G31.4 External Skip Function 4
G32 G33 G33 01 Constant Lead Thread Cutting Modal
G34 Variable Lead Thread Cutting
Modal
G36 22 Short Block Acc/Dec (Enable)
G36.1 Short Block Acc/Dec (Disable)
G37 00 Tool Gauging Skip Function 1 Nonmodal
G37.1 Tool Gauging Skip Function 1
G37.2 Tool Gauging Skip Function 2
G37.3 Tool Gauging Skip Function 3
G37.4 Tool Gauging Skip Function 4
G39 20 Tool Tip Radius Compensation (Linear Generated Block) Modal
G39.1 Tool Tip Radius Compensation (Circular Generated Block)
Modal
G40 07 Tool Tip Radius Compensation (Cancel)
G41 Tool Tip Radius Compensation (Left)
G42 Tool Tip Radius Compensation (Right)
