Displays and Graphics
Chapter 8
8-38
4. Press the
{ENTER MESAGE}
softkey. This highlights the softkey, and
the control displays the input prompt “PTO MESSAGE:” at the top of
the screen. Also, the current text, if any, of the selected message line
is shown on the input line next to the prompt. (The text may be
edited like any other input string.)
(softkey level 3)
ENTER
MESAGE
STORE
BACKUP
5. Once the line has been edited, press the key. This
transfers the edited line to the PTO screen. After pressing the
key, you can either:
edit another line
exit the PTO screen by pressing the up arrow softkey
6. To save changes to the system integrator message lines, press the
{STORE BACKUP}
softkey. When pressed, the softkey will be shown
in reverse video until the control has finished storing the lines.
Important: If the messages are not stored to EEPROM, the text will be
lost the next time the system is powered down.
(softkey level 3)
ENTER
MESAGE
STORE
BACKUP
The 9/Series screen saver utility is designed to reduce the damage done to
the CRT from “burn in”. Burn in is the result of the same lines or
characters being displayed at the same location on the screen for a such a
long period of time that they leave a permanent imprint on the CRT.
After a preset length of time without any keyboard strokes, the screen
saver utility replaces the 9/Series display with a single horizontal line that
continuously scrolls from top to bottom on the CRT. This horizontal line is
a standard character high, green on color operator panels, amber on
monochrome.
When any operator panel key, PAL keyboard request, or softkey is pressed,
the display is returned to the last viewed 9/Series display. Exceptions are
screens accessed through hot keys on the keyboard (such as Display Select
or the PAL rung monitor). When the screen saver returns from one of
these screens, the 9/Series screen previous to the hot key selection is
displayed.
8.6
Screen Saver
