Editing Part Programs Off Line
Chapter 6
6-5
After you select a file, the workstation displays a screen explaining
the text editor:
F1 - File F2 - Project F3 - Application F4 - Utility F5 - Configuration
Proj: Demo Appl: Part Program Util: File Management
The configured text editor will now be executed,
using the file name selected.
Press any key to continue...
Use the configured screen or text editor to edit part programs. The editor
must be compatible with the ODS operating system. The editor must be
configured using the Text Editor Setup option of the F5-Configuration
menu at the main menu line. For details on how to use a specific screen or
text editor, such as ending an edit session, displaying a program, etc., see
the documentation provided with the screen or text editor.
You can find details about programming blocks in later chapters.
Important: The end of block statements, ”;” used to separate blocks on the
control should not be entered with the screen or text editor. The control
automatically inserts the end of block statements ”;” at the end of each line
when the program is downloaded to the control.
The maximum number of programs that you can have is 328. To store a
program, it must use at least 1.3 meters of memory. Use this table to find
out how much part program space there is in your system.
If your system has this is your part program storage
64K 150 meters
128K 300 meters
192K 450 meters
Extended Part Program Storage (EPPS) 5235 meters
Extended Part Program Storage is not available on 9/230 CNCs.
