AT91CAP9S500A/AT91CAP9S250A
Before performing the jump to the application in internal SRAM, all the PIOs and peripherals
used in the boot program are set to their reset state.
Table 14-7.
Pins Driven during Boot Program Execution
Peripheral
Pin
PIO Line
SPI0
MOSI PIOA1
SPI0
MISO
PIOA0
SPI0
SPCK
PIOA2
SPI0
NPCS0
PIOA5
PIOD
NANDCS
PIOD15
Address Bus
NAND ALE
A21
Address Bus
NAND CLE
A22
DBGU
DRXD
PIOC30
DBGU
DTXD
PIOC31
