102
6264A–CAP–21-May-07
AT91CAP9S500A/AT91CAP9S250A
16.4.1 Real-time Timer Mode Register
Register Name: RTT_MR
Access Type: Read/Write
• RTPRES: Real-time Timer Prescaler Value
Defines the number of SLCK periods required to increment the Real-time timer. RTPRES is defined as follows:
RTPRES = 0: The prescaler period is equal to 2 16
RTPRES
≠
0: The prescaler period is equal to RTPRES.
• ALMIEN: Alarm Interrupt Enable
0 = The bit ALMS in RTT_SR has no effect on interrupt.
1 = The bit ALMS in RTT_SR asserts interrupt.
• RTTINCIEN: Real-time Timer Increment Interrupt Enable
0 = The bit RTTINC in RTT_SR has no effect on interrupt.
1 = The bit RTTINC in RTT_SR asserts interrupt.
• RTTRST: Real-time Timer Restart
1 = Reloads and restarts the clock divider with the new programmed value. This also resets the 32-bit counter.
31 30 29 28 27 26 25 24
– – – – – – – –
23 22 21 20 19 18 17 16
– – – – – RTTRST RTTINCIEN ALMIEN
15 14 13 12 11 10 9 8
RTPRES
7 6 5 4 3 2 1 0
RTPRES
