background image

370

6264A–CAP–21-May-07

AT91CAP9S500A/AT91CAP9S250A

29.9.6

PMC Peripheral Clock Status Register

Register Name:

PMC_PCSR

Access Type:

Read-only

• PIDx: Peripheral Clock x Status

0 = The corresponding peripheral clock is disabled.

1 = The corresponding peripheral clock is enabled.

Note:

PID2 to PID31 refer to identifiers as defined in the section “Peripheral Identifiers” in the product datasheet.

31

30

29

28

27

26

25

24

PID31

PID30

PID29

PID28

PID27

PID26

PID25

PID24

23

22

21

20

19

18

17

16

PID23

PID22

PID21

PID20

PID19

PID18

PID17

PID16

15

14

13

12

11

10

9

8

PID15

PID14

PID13

PID12

PID11

PID10

PID9

PID8

7

6

5

4

3

2

1

0

PID7

PID6

PID5

PID4

PID3

PID2

–

–
