AT91CAP9S500A/AT91CAP9S250A
3.
Signal Description
gives details on the signal name classified by peripheral.
Table 3-1.
Signal Description List
Signal Name
Function
Type
Active
Level
Comments
Power Supplies
VDDIOM
EBI I/O Lines Power Supply
Power
1.65V to 3.6V
VDDIOP0
Peripherals I/O Lines Power Supply
Power
3.0V to 3.6V
VDDIOP1
Peripherals I/O Lines Power Supply
Power
1.65V to 3.6V
VDDIOMPA
MP Block I/O A Lines Power Supply
Power
1.65V to 3.6V
VDDIOMPB
MP Block I/O B Lines Power Supply
Power
1.65V to 3.6V
VDDBU
Backup I/O Lines Power Supply
Power
1.08V to 1.32V
VDDPLL
PLL Power Supply
Power
3.0V to 3.6V
VDDUTMII
USB UTMI+ Interface Power Supply
Power
3.0V to 3.6V
VDDUTMIC
USB UTMI+ Core Power Supply
Power
1.08V to 1.32V
VDDUPLL
USB UTMI+ PLL Power Supply
Power
1.08V to 1.32V
VDDANA
ADC Analog Power Supply
Power
3.0V to 3.6V
VDDCORE
Core Chip Power Supply
Power
1.08V to 1.32V
GND
Ground
Ground
GNDPLL
PLL Ground
Ground
GNDUTMII
USB UTMI+ Interface Ground
Ground
GNDUTMIC
USB UTMI+ Core Ground
Ground
GNDUPLL
USB UTMI+ PLL Ground
Ground
GNDANA
ADC Analog Ground
Ground
GNDBU
Backup Ground
Ground
GNDTHERMAL
Thermal Ground Ball
Ground
Thermally coupled with
package substrate
Clocks, Oscillators and PLLs
XIN
Main Oscillator Input
Input
XOUT
Main Oscillator Output
Output
XIN32
Slow Clock Oscillator Input
Input
XOUT32
Slow Clock Oscillator Output
Output
PLLRCA
PLL A Filter
Input
PLLRCB
PLL B Filter
Input
PCK0 - PCK3
Programmable Clock Output
Output
Shutdown, Wakeup Logic
SHDN
Shutdown Control
Output
Do not tie over VDDBU
WKUP
Wake-Up Input
Input
Accept between 0V and
VDDBU
