6-76 Specifications
Version 2.2 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
Table 6.52 Alphanumeric List by BGA Position
A1 VDD_IO
A2 VDD_IO
A3 NC
A4 NC
A5 VSS_IO
A6 VDD_IO
A7 NC
A8 NC
A9 VSS_IO
A10 VDD_IO
A11 B_RBIAS
A12 NC
A13 VSS_IO
A14 VDD_IO
A15 NC
A16 NC
A17 VSS_IO
A18 VDD_IO
A19 NC
A20 NC
A21 VSS_IO
A22 VDD_IO
A23 NC
A24 NC
A25 VSS_IO
A26 VDD_IO
B1 VSS_IO
B2 NC
B3 NC
B4 VSSC
B5 NC
B6 NC
B7 NC
B8 NC
B9 NC
B10 NC
B11 NC
B12 NC
B13 B_VDDBIAS
B14 NC
B15 NC
B16 NC
B17 NC
B18 NC
B19 NC
B20 NC
B21 NC
B22 NC
B23 NC
B24 NC
B25 NC
B26 VSS_IO
C1 VDDA
C2 NC
C3 NC
C4 VSS_IO
C5 NC
C6 NC
C7 VDD_IO
C8 VSS_IO
C9 NC
C10 NC
C11 VDD_IO
C12 VSS_IO
C13 NC
C14 NC
C15 VDD_IO
C16 VSS_IO
C17 NC
C18 NC
C19 VDD_IO
C20 VSS_IO
C21 VSSC
C22 NC
C23 VDD_IO
C24 NC
C25 NC
C26 VSSC
D1 SD11+
D2 VDDC
D3 VDD_IO
D4 NC
D5 NC
D6 VDDC
D7 TEST_HSC
D8 NC
D9 NC
D10 NC
D11 NC
D12 NC
D13 NC
D14 NC
D15 NC
D16 NC
D17 NC
D18 NC
D19 NC
D20 NC
D21 NC
D22 NC
D23 NC
D24 VSS_IO
D25 MAD2
D26 MAD7
E1 VSS_IO
E2 A_DIFFSENS
E3 NC
E4 NC
E5 NC
E6 NC
E7 SCAN_MODE
E8 NC
E9 NC
E10 NC
E11 NC
E12 NC
E13 NC
E14 NC
E15 NC
E16 NC
E17 NC
E18 NC
E19 VDDC
E20 NC
E21 NC
E22 NC
E23 NC
E24 NC
E25 MAD6
E26 VDD_IO
F1 VDD_IO
F2 SD11
−
F3 SCLK
F4 NC
F5 NC
F22 NC
F23 MAD1
F24 MAD4
F25 VSSC
F26 VSS_IO
G1 SD10+
G2 SD10
−
G3 VSS_IO
G4 VSSC
G5 NC
G22 MAD0
G23 MAD3
G24 VDD_IO
G25 MCE/
G26 MOE/
H1 SD8
−
H2 SD8+
H3 VDD_IO
H4 SD9+
H5 VSSA
H22 MAD5
H23 MWE/
H24 VSS_IO
H25 GPIO3
H26 GPIO0
J1 VSS_IO
J2 SREQ
−
J3 SREQ+
J4 SD9 −
J5 SIO+
J22 VDDC
J23 GPIO4
J24 MAS1/
J25 GPIO1
J26 VDD_IO
K1 VDD_IO
K2 SSEL+
K3 SCD
−
K4 SCD+
K5 SIO
−
K22 MAS0/
K23 NC
K24 GPIO2
K25 NC
K26 VSS_IO
L1 SMSG+
L2 SMSG
−
L3 VSS_IO
L4 SSEL
−
L5 SACK+
L11 VSS_IO
L12 VSS_IO
L13 VSS_IO
L14 VSS_IO
L15 VSS_IO
L16 VSS_IO
L22 VSSC
L23 NC
L24 VDD_IO
L25 NC
L26 AD34
M1 SRST
−
M2 SRST+
M3 VDD_IO
M4 SATN
−
M5 SACK
−
M11 VSS_IO
M12 VSS_IO
M13 VSS_IO
M14 VSS_IO
M15 VSS_IO
M16 VSS_IO
M22 VDDC
M23 NC
M24 VSS_IO
M25 NC
M26 AD35
N1 VSS_IO
N2 NC
N3 SBSY
−
N4 SBSY+
N5 SATN+
N11 VSS_IO
N12 VSS_IO
N13 VSS_IO
N14 VSS_IO
N15 VSS_IO
N16 VSS_IO
N22 SCANEN
N23 NC
N24 AD32
N25 AD33
N26 VDD_IO
P1 VDD_IO
P2 NC
P3 SD7+
