Page 99: Creating a program

Chapter

6–1

Creating a Program

In this chapter you create a ladder program. The tasks you will perform are:

•

configure your SLC 500 controller

•

name your program

A program is always created offline using the HHT. In creating the program,
you:

1. Clear the memory of the HHT.

2. Configure the processor.

3. Configure the I/O.

4. Name the ladder program and main program file.

Clearing the Memory of the HHT

To create a new program, clear the HHT memory (

DEFAULT

program).

1. Energize your HHT. After it goes through the self–diagnostic tests, the

main menu display appears:

SLC 500 PROGRAMMING SOFTWARE Rel. 2.03

1747 – PTA1E

PRESS A FUNCTION KEY
SELFTEST

TERM PROGMAINT

OFL

UTILITY

Creating a Program Offline
with the HHT
