Chapter 7
Creating and Editing a Program File
7–8
3. Press [F5] , ACCEPT, then press [ESC] twice to move up through the
menu displays. Now press [F5] , ACP_RUNG.
The following display appears:
<
END
>
F1 F2 F3 F4 F5
>
2.1.0.0.*
INS_RNG MOD_RNG SEARCH DEL_RNG UND_RNG
OFL
] [ ( )
Notice the I symbol in the power
rails has changed to a solid line,
indicating the rung is accepted
into the program.
Important: Saving and compiling your ladder program is explained in
detail, in the next chapter. But before you continue with the
additional editing examples, save the work you have done so
far. Whenever you are adding or editing rungs of a program it
is recommended to periodically save your program. In the
event of a power loss to the HHT, any edits that you have made
up to this point are not recoverable.
4. At this point the rung is entered and accepted. Now save this rung and
continue editing. Press [ENTER] to display additional menu options.
<
END
>
F1 F2 F3 F4 F5
>
2.1.0.0.*
EDT_DAT SAVE_CT SAVE_EX
OFL
] [ ( )
5. To save and continue editing, press [F4] , SAVE_CT, then press [F5] ,
ACCEPT.
Adding a Rung with Branching
Refer to chapter 5 for a description and example of different types of
branching.
