Chapter 1
Features, Installation, Powerup
1–12
ZOOM and RUNG Keys
The [ZOOM] key brings up a display that shows the parameters of an
instruction.
The [RUNG] key moves the cursor to a particular rung. Using this key saves
time when you have a long ladder diagram. When you press [RUNG] , you are
prompted for the rung number that you want to edit or monitor. Enter the
rung number and press
[ENTER] , the cursor moves to the selected rung and
the rung appears at the top of the display.
] [
OFL
INS RNG MOD RNG SEARCH DEL RNG UND RNG >
F1 F2 F3 F4 F5
TON:T4:2 2.2.0.0.2
( )
( )
( )
( ) ] [
(TON)
F1 F2 F3 F4 F5
ZOOM on TON –(TON)– 2.2.0.0.2
NAME: TIMER ON DELAY
TIMER: T4:2 TIME BASE .01 SEC
PRESET: 20
ACCUM: 0
EDT_DAT
Press the [ZOOM] key
with the cursor on an
instruction. The Zoom
display shows the
instruction parameters.
Exit the Zoom display by
pressing
[ESC] or
[ZOOM] .
] [
] [
] [
(TON) ] [
OFL
INS RNG MOD RNG SEARCH DEL RNG UND RNG >
F1 F2 F3 F4 F5
TON:T4:2 2.6.0.0.*
( )
( )
( )
( ) ] [
] [
] [
] [
Press [RUNG][6][ENTER] .
The cursor moves from the Timer
rung to the left power rail of rung 6.
