Chapter 27
The Status File
27–20
Fault Classification Processor
Description User
Address
Error
Code
(Hex)
User Program Instruction Errors Non-User Non-Recov Recov 5/02
5/01,
Fixed
S:6 0030 Attempt was made to jump to one too many nested
subroutine files. Can also mean that a program has
potentially recursive routines. X
• •
0031 Unsupported instruction reference was detected. X
• •
0032 Sequencer length/position points past end of data file. X
• •
0033 Length of LFU, LFL, FFU, FFL, BSL, or BSR points past end
of data file. X
• •
0034 A negative value for a timer accumulator or preset value was
detected. X
• •
Fixed processors with 24 VDC inputs only: A negative or
zero HSC preset was detected in an HSC instruction. X
•
0035 TND, SVC, or REF instruction is called within an interrupting
or user fault routine. X
•
0036 Invalid value for a PID parameter. This code is discussed in
chapter 26. X
•
0038 A RET instruction was detected in a non-subroutine file. X
• •
