Chapter 7
Creating and Editing a Program File
7–11
Entering a Parallel Branch
The five branching instructions available on the HHT are listed below.
Function Key Description
[ F1 ], Extend Up Adds a parallel branch above the cursored branch.
[ F2 ], Extend Down Adds a parallel branch below the cursored branch.
[ F3 ], Append Branch
Places the starting point of a branch to the right of the
cursored instruction or at the cursor.
[ F4 ], Insert Branch
Places the starting point of the branch to the left of the
cursored instruction or at the cursor.
[ F5 ], Delete Branch
Removes a branch and the instructions within the branch
from a rung.
In this example use the insert branch command. The other branching
commands are described starting on page 7–19.
1. Starting from the previous display, press [ESC] twice to bring up the
following menu display:
< END >
F1 F2 F3 F4 F5
>
2.1.0.0.1
OFL
] [ ( )
I I ] [ ( )
OTE:O0:3.0/1 NO FORCE
INS_INST BRANCH MOD_INST ACP_RNG
2. Press [F2] , BRANCH. The display shows the various branching
instructions:
< END >
F1 F2 F3 F4 F5
2.1.0.0.1
OFL
] [ ( )
I I ] [ ( )
OTE:O0:3.0/1 NO FORCE
EXT_UP EXT_DWN APP_BR DEL_BR INS_BR
