Chapter 7
Creating and Editing a Program File
7–44
Searching for Rungs
You can search for a specific rung number by using the rung key located at
the lower right corner of the keypad:
F1 F2 F3 F4 F5
N O
SPACE PRE/LEN
S
ACC/POS
I
U
ESC
A
7
D
4
T
1
B
8
E
5
R
2
#
0
–
: /
.
C
9
F
6
M
3
SHIFT
ENTER
ZOOM RUNG
Press [RUNG] , type the desired rung
number, and then press [ENTER] .
To use the search rung function you must be in either the offline, edit file
display or the online, monitor file display.
1. To search for rung 3, start at the following display with the cursor located
on the left power rail of rung 0.
] [ ] [
2.0.0.0.*
F1 F2 F3 F4 F5
] [ ( )
] [
] [ ( )
( )
] [ ] [ ] [
] [ ( ) ] [
] [ ( ) ] [ ] [ ] [
> INS_RNG MOD_RNG SEARCH DEL_RNG UND_RNG
OFL
2. Press [RUNG] . The following prompt appears:
] [ ] [
2.0.0.0.*
F1 F2 F3 F4 F5
] [ ( )
] [
] [ ( )
( )
] [ ] [ ] [
] [ ( ) ] [
] [ ( ) ] [ ] [ ] [
> INS_RNG MOD_RNG DEL_RNG UND_RNG
OFL ENTER RUNG NUMBER:
SEARCH
