Instruction Execution Times
Appendix C
Memory Usage,
C–8
Instruction Execution Times for the SLC 5/02 Processor Series A or B
Instruction
(Series A or B
SLC 5/02)
MSG
80
300
➁
MUL
12
234
MVM
12
119
NEG
12
114
NEQ
➀
12
64
NOT
12
70
OR
12
91
OSR
12
34
OTE
18
18
OTL
19
19
OTU
19
19
PID
150
6000
REF
6
400 +
300 per word
RES
12
44
RET
12
34
RPI
12
400
RTO
12
144
SBR
2
6
SCL
12
800
SQC
12
229
SQL
60
225
SQO
12
229
SQR
12
270
STD
6
15
STE
6
15
STS
12
120
SUB
12
129
SUS
12
12
SVC
6
400
TND
12
36
TOD
12
204
TOF
12
144
TON
12
139
XIC
➀
4
4
XIO
➀
4
4
XOR
12
91
For the rung example below:
1) If instruction 1 is false, instructions 2, 3, 4, 5, 6, 7
take zero execution time.
Execution time = 4 + 18 = 22 microseconds.
2) If instruction 1 is true, 2 is true, and 6 is true, then
instructions 3, 4, 5, 7 take zero execution time.
Execution time = 4 + 4 + 4 + 18 = 30
microseconds.
Execution Time
in Microseconds
(approx.)
False
True
ADD
12
126
AND
12
91
BSL
12
148 + 24 per word
BSR
12
138 + 24 per word
CLR
12
44
COP
12
49 + 21 per word
CTD
12
115
CTU
12
115
DCD
12
84
DDV
12
654
DIV
12
404
EQU
➀
12
64
FFL
85
250
FFU
85
250 +
18 x position value
FLL
12
41 + 14 per word
FRD
12
227
GEQ
➀
12
64
GRT
➀
12
64
IID
12
65
IIE
12
70
IIM
12
552
INT
0
0
IOM
12
767
JMP
12
38
JSR
12
46
LBL
2
6
LEQ
➀
12
64
LES
➀
12
64
LFL
85
250
LFU
85
300
LIM
12
75
MCR
10
10
MEQ
➀
12
79
MOV
12
24
Execution Time
in microseconds
(approx.)
False
True
Instruction
(Series A or B
SLC 5/02)
➁
This only includes the amount of time needed
to “set up” the operation requested. It does not
include the time it takes to service the actual
communications.
] [
1
( )
8
] [
2
] [
6
] [
3
] [
4
] [
5
] [
7
➀
These instructions take zero execution time if
they are preceded by conditions that guarantee
the state of the rung. Rung logic is solved left
to right. Branches are solved top to bottom.
