Chapter 21
Move and Logical Instructions
21–2
Overflow Trap Bit, S:5/0
Minor error bit set upon detection of a mathematical overflow or division by
0. If this bit is set upon execution of the END statement or a TND
instruction, a major error will be declared.
Math Register, S:13 and S:14
Move and logical instructions do not affect the math register.
Move MOV Output Instruction
(MOV)
MOV
MOVE
Source
N7:0
9760
Dest N7:1
9760
F1 F2 F3 F4 F5
ZOOM on MOV –(MOV)– 2.3.0.0.2
NAME: MOVE
SOURCE: N7:0 9760
DEST: N7:1 9760
EDT_DAT
HHT Ladder Display:
HHT Zoom Display:
Ladder Diagrams and APS Displays:
(online monitor mode)
The processor moves a copy of the source value to the destination location.
Entering Parameters
•
Source – a program constant or the address of the data you want to move.
•
Destination – the address where the instruction moves the data.
Move (MOV)
