Chapter 14
Using EEPROMs and UVPROMs
14–4
7. To transfer a program from an EEPROM with matching programs in the
HHT and the processor, begin at the following display:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
OFFLINE UPLOAD DWNLOAD MODE
PRG
CLR_PRC>
To view the remaining menu selections, press [ ENTER ].
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
PASSWRD XFERMEM EDT_DAT
PRG
MONITOR>
8. Press [ F3 ], XFERMEM:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
MEM_PRC PRC_MEM
PRG
Your choices are memory module to processor RAM (MEM_PRC) and
processor RAM to memory module (PRC_MEM).
9. To transfer the program from the memory module to the processor RAM,
press [ F2 ], MEM_PRC.
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
XFER MEMORY MODULE TO PROC?
F1 F2 F3 F4 F5
PRG
YES NO
The prompt line asks you to verify your choice.
