Chapter 12
Monitoring Controller Operations
12–4
The following HHT display shows the ladder program being monitored in
the online mode. The cursor is located on the XIC instruction C5:0/DN on
rung 2.
(CTU)
(RES)
] [ ] [
2.2.0.0.1
] [
F1 F2 F3 F4 F5
( )
( )
] [ ] [ ] [
MODE FORCE EDT_DAT SEARCH
RUN
] [
] [
( )
XIC:C5:0/13
When you are monitoring a file, the location of the cursor in the ladder
program determines how you access a particular address within a data file:
•
If the cursor is on an instruction when you press [ F3 ], EDT_DAT, the
cursor moves to the address (bit or word level) of the instruction in the
appropriate data file.
•
If the cursor is on a power rail or branch intersection when you press [ F3 ],
EDT_DAT, the cursor moves to the beginning of the first data file, the
Output data file. You can then use the ADDRESS function key, followed
by [
ENTER ] to specify any address in the data table.
Monitor the counter data file by pressing [ F3 ], EDT_DAT. The following
display appears:
ADDRESS NEXT FL PREV FL NEXT PG PREV PG
F1 F2 F3 F4 F5
COUNTER C5:0
CU CD DN OV UN UA
STATUS 0 0 0 0 0 0
PRESET 3
ACCUM 0
STATUS=000 000 RUN
Function Key Description
[ F1 ], ADDRESS Locates any address in the data table
[ F2 ], NEXT_FL Displays the next consecutive file in the data table
[ F3 ], PREV_FL Displays the previous file in the data table
[ F4 ], NEXT_PG Displays the next page of elements in the existing data file
[ F5 ], PREV_PG
Displays the previous page of elements in the existing data
file
