Chapter 9
Configuring Online Communication
9–2
To configure your HHT for online communication, begin at the main menu
display of the HHT.
SLC 500 PROGRAMMING SOFTWARE Rel. 2.03
1747 – PTA1E
Allen–Bradley Company Copyright 1990
All Rights Reserved
F1 F2 F3 F4 F5
PRESS A FUNCTION KEY
SELFTEST
TERM PROGMAINT
OFL
UTILITY
Press [F5] , UTILITY. The following display appears:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 76
1 Reserved 0
2 222 Ladder 56
3 Ladder 0
F1 F2 F3 F4 F5
ONLINE WHO PASSWRD
OFL
CLR_MEM
The following functions are available from this display:
Function Key Description
[ F1 ], ONLINE
Allows you to go online and communicate with
the processor you were previously attached to.
If you were not previously attached to a
processor, the Who function is entered.
[ F2 ], WHO
Allows you to view the nodes on the network, run
network diagnostics, attach to and communicate
with a specific node, change a node
configuration, and set and clear ownership.
[ F3 ], PASSWRD
Allows you to change a password in the HHT
offline program.
[ F4 ], CLR_MEM Allows you to clear the HHT offline memory.
In the following example, go online to the processor at node address 4.
Assume that the HHT has previously been attached to node 4, and that the
program in the HHT and the program in the processor are identical.
From the UTILITY menu, press [F1] , ONLINE. The display changes as
follows:
File Name: 222 Prog Name:1000
File Name Type Size(Instr)
0 System 77
1 Reserved 0
2 222 Ladder 13
3 Ladder 1
F1 F2 F3 F4 F5
OFFLINE UPLOAD DWNLOAD
RUN
CLR_PRC MODE
Display toggles between the
processor node address and
the processor operating
mode.
>
