Chapter 9
Configuring Online Communication
9–6
Diagnostics
1. To monitor the diagnostics of the network or the selected node, press
[F1]
, DIAGNSTC from the Who display. The following display appears:
Node Addr.
Device Max Addr./Owner
2
5/02
(31)
3
500–20
(31)
4
5/01
(31)
0
APS
(31)
Node Addr: 2 Baud Rate: 19200
F1
F2
F3
F4
F5
NODE
OFL
NETWORK
2. To monitor the diagnostic display of the selected node press
[F1]
, NODE.
The following display appears:
Node: 2 Device Type:
5/02
Firmware Rel: 5 Series: C
Mode:
PRG
Fault Code:
0000H
Program Name
1000
Forces:
Not Installed
F1
F2
F3
F4
F5
OFL
3. To monitor the diagnostic display of the network press
[ESC]
, then
[F5]
, NETWORK.
The following display appears:
Total Nodes:
5
Max. Addr.:
31
Msgs Sent: 29736
Msgs Rcvd: 202
Retries:
0
Limit Exceeded: 0
Bad Msgs Rcvd: 0
NAK Sent:
0
NAK Rcvd:
0
Node Addr: 2
F1
F2
F3
F4
F5
OFL
RESET
4. From this display, you can reset the messages sent and messages received
counters by pressing
[F5]
, RESET.
5. Press
[ESC]
twice to return to the Who menu.
