Chapter 15
Instruction Set Overview
15–6
Move and Logical Instructions – Chapter 21
Instruction Name
and Mnemonic
5/02
Only
•
Function – Output Instructions
Move MOV When rung conditions are true, the MOV instruction
moves a copy of the source to the destination.
Masked Move MVM When rung conditions are true, the MVM instruction
moves a copy of the source through a mask to the
destination.
And AND When rung conditions are true, sources A and B of the
AND instruction are ANDed bit by bit and stored in the
destination.
Inclusive Or OR When rung conditions are true, sources A and B of the
OR instruction are ORed bit by bit and stored in the
destination.
Exclusive Or XOR When rung conditions are true, sources A and B of the
XOR instruction are Exclusive ORed bit by bit and
stored in the destination.
Not NOT When rung conditions are true, the source of the NOT
instruction is inverted (0
→
1, 1
→
0) bit by bit and stored
in the destination.
File Copy and File Fill Instructions – Chapter 22
Instruction Name
and Mnemonic
5/02
Only
•
Function – Output Instructions
File Copy COP When rung conditions are true, the COP instruction
copies a user-defined source file to the destination file.
File Fill FLL When rung conditions are true, the FLL instruction
loads a source value into a specified number of
elements in a user-defined file.
