Appendix D
Estimating Scan Time
D–4
Worksheet B — Estimating the Scan Time of Your 1747–L511 or 1747–L514 Processor
Procedure Min Scan Time Max ScanTime
1. Estimate your input scan time (
µ
s).
A. Calculate the processor input scan of your discrete input modules.
Number of 8 point modules ________ x 197 = a.)________
Number of 16 point modules ________ x 313 = b.)________
Number of 32 point modules ________ x 545 = c.)________
B. Calculate the processor input scan of your specialty I/O modules.
Number of 1/4 DCM or analog combo ________ x 652 = d.)________
Number of 1/2 DCM, analog input, 1746–HS ________ x 1126 = e.)________
Number of 3/4 DCM ________ x 1600 = f.)________
Number of full DCM, BASIC, or 1747–DSN ________ x 2076 = g.)________
Number of 1747–KE ________ x 443 = h.)________
C. Add lines a through h. Place this value on line (i)
Add 101 to the value on line (i). This sum is your minimum input scan time. i.)________ + 101 =
D. Calculate your maximum input scan time:
Maximum input scan time = Minimum scan time + (Number of specialty I/O modules x 50)
E. Calculate the Forced Input Overhead: Forced Input Overhead =
(Number of input modules x 180) + 140 per additional word for multi–word modules (e.g. DCM, analog, DSN)
_________
_________
_________
2. Estimate your output scan time ( µ s).
A. Calculate the processor output scan of your discrete output modules.
Number of 8 point modules ________ x 173 = a.)________
Number of 16 point modules ________ x 272 = b.)________
Number of 32 point modules ________ x 470 = c.)________
B. Calculate the processor output scan of your specialty I/O modules.
Number of 1/4 DCM or analog combo ________ x 620 = d.)________
Number of 1/2 DCM, analog output, or 1746–HS ________ x 1028 = e.)________
Number of 3/4 DCM ________ x 1436 = f.) ________
Number of full DCM, BASIC, or 1747–DSN ________ x 1844 = g.)________
C. Add lines a through g. Place this value on line (h).
Add 129 to the value on line (h). This sum is your minimum output scan time. h.)________ + 129 =
D. Calculate your maximum output scan time:
Maximum output scan time = Minimum scan time + (Number of specialty I/O modules x 50)
E. Calculate the Forced Output Overhead: Forced Output Overhead =
(Number of output modules x 172) + 140 per additional word for multi–word modules (e.g. DCM, analog, DSN)
________
_________
_________
3. Estimate your program scan time. This estimate assumes operation of all instructions once per operating scan.
A. Count the number of rungs in your APS program. Place value on line (a).
B. Multiply value on line (a) by 1.
a.)________ x 1 =
C. Calculate your program execution time when all instructions are true. (See appendix A to do this.)
4. Add the values in the minimum and maximum scan time columns.
__________
__________
_________ __ subtotal
_________
_________
_________ subtotal
5. Add processor overhead time (178 for min scan time; 278 for max. scan time) to the subtotals estimated in
step 4. Use these new subtotals to calculate communications overhead in step 6.
+ 178
__________subtotal
+ 278
_________ subtotal
6. Estimate your communication overhead:
A. Calculate the background communication overhead: multiply the subtotal for minimum scan time (estimated in
step 5) by 1; multiply the subtotal for maximum scan time by 1.140 (max. value accounts for active DH–485 link).
B. Calculate the foreground communication overhead: for minimum scan time add 0; for maximum scan time
add 2310. (Maximum scan time accounts for programmer being attached to processor.)
C. Convert
µ
secs. to msecs., divide by 1000.
x 1.000
__________
µ
secs.
+ 0
__________
µ
secs.
/ 1000
x 1.140
_________
µ
secs.
+ 2310
_________
µ
secs.
/ 1000
Estimated minimum and maximum scan times for your 1747–L511 or 1747–L514 application: msecs. msecs.
