Chapter 7
Creating and Editing a Program File
7–34
12. Since you are assigning an input address from a different slot, press the
[
→
] key three times, then press [2] . Press the [
→
] key three more times,
then press [0] , then [ENTER] . Verify that the new address is correct, then
press [F5] , ACCEPT.
13. Press the [
→
] key, then [ZOOM] to change the output address. The zoom
display for the output energize instruction appears:
ZOOM on OTE
NAME: OUTPUT
ENERGIZE
BIT ADDR: O0:3.0/0
F1 F2 F3 F4 F5
2.2.0.0.3 ( )
EDT_DAT ACCEPT
ENTER BIT ADDR: O0:3.0/0
14. Press the [
→
] key seven times to position the cursor on the bit element.
15. Press [3 ], then [ENTER] , then [F5] , ACCEPT.
16. To complete editing this rung, press [ESC] , then [F5] , ACP_RNG.
17. Repeat the above procedure for the instructions in rung 3.
18. Save and compile your changes.
Abandoning Edits
If you have made changes that you do not want and they are not saved, press
[ESC] and [F2] , YES. This deletes your edits up to the last program save.
