Chapter 7
Creating and Editing a Program File
7–39
2. Press [F3] , SEARCH. The search display appears:
] [ ] [
2.0.0.0.*
F1 F2 F3 F4 F5
] [ ( )
] [
] [ ( )
( )
] [ ] [ ] [
] [ ( ) ] [
] [ ( ) ] [ ] [ ] [
CUR–INS CUR–OPD NEW–INS FORCE UP
OFL +
3. To search for the specific address, press [SHIFT] , then type the
abbreviated form of the address, I:1/1 . Then press [ENTER] to place the
address into the search buffer:
The address is
displayed in the
search buffer.
] [ ] [
2.0.0.0.*
F1 F2 F3 F4 F5
] [ ( )
] [
] [ ( )
( )
] [ ] [ ] [
] [ ( ) ] [
] [ ( ) ] [ ] [ ] [
CUR–INS CUR–OPD NEW–INS FORCE UP
OFL + I:1/1
4. Press [ENTER] again, to find the first occurrence of the address, which is
the second instruction in rung 0.
] [ ] [
] [ ] [
F1 F2 F3 F4 F5
] [ ( )
] [
] [ ( )
( )
] [
] [ ( ) ] [
] [ ( ) ] [ ] [ ] [
CUR–INS CUR–OPD NEW–INS FORCE UP
OFL + I:1/2
NO FORCE XIC:I1:1.0/1 2.0.0.0.2
5. Press [ENTER] again, to find the next occurrence of the address, which is
located in rung 1, nest level 1, branch level 1, instruction number 2:
] [ ] [
F1 F2 F3 F4 F5
] [
] [ ( )
( )
] [ ( ) ] [
( ) ] [ ] [
CUR–INS CUR–OPD NEW–INS FORCE UP
OFL + I:1/1
NO FORCE XIC:I1:1.0/1 2.1.1.1.2
