Chapter 6
Creating a Program
6–3
2. Use the cursor keys
[
↑
]
or
[
↓
]
then press
[ENTER]
to select the correct
processor type. For this example, select the 1747–L511 processor. Since
this is the default selection on the display, press
[ENTER]
. Processor
module 1747–L511 is entered into memory. The previous display
appears.
3. Press
[ESC]
to return to the following display:
File Name:
Prog Name:DEFAULT
File Name
Type
Size(Instr)
0
System
*
1
Reserved
*
2
Ladder
*
F1
F2
F3
F4
F5
EDT_DAT SEL_PRO EDT_I/O
OFL
CLR_MEM
>
Configuring the I/O
1. Press
[F3]
, EDT_I/O. The following display appears:
Rack 1 = 1746–A4
4–SLOT RACK
Rack 2 = NONE
Rack 3 = NONE
Slot 0 = 1747–L511
CPU–1K USER MEMORY
Slot 1 = NONE
F1
F2
F3
F4
F5
MOD_RCK MOD_SLT DEL_SLT UND_SLT
The display shows that the processor module we just entered is assigned
to slot 0. It also shows the default rack selection 1746–A4. For this
example you do not have to change the rack selection. If you are using a
different rack, press
[F1]
, MOD_RCK, then
[F1]
, RACK 1. Select the
appropriate rack, using the
[
↓
]
and
[
↑
]
keys, then press
[ENTER]
.
If you are using more than one rack, follow the same procedure for racks
2 and 3. The next task is to assign the I/O module slots. For this
example, use slots 1, 2, and 3.
2. Press
[F2]
, MOD_SLT.
The following display appears:
Rack 1 = 1746–A4
4–SLOT RACK
Rack 2 = NONE
Rack 3 = NONE
Slot 0 = 1747–L511
CPU–1K USER MEMORY
Slot 1 = NONE
Slot 1 = NONE
F1
F2
F3
F4
F5
OTHER
Slot 1 = NONE
appears on the prompt line.
